Advantages - Based on the advanced Wise-Eye algorithm platform, excellent high-precision detection can be achieved. - Standard AI algorithm is simple and intelligent, without any experience, according to the wizard automatic learning can quickly add new products. - Customized AI algorithm is suitable for special products. Standard algorithm and customized algorithm can detect in parallel to further improve the detection accuracy. - The main engine is integrated with fast pneumatic push rod, and the high-speed production line can be accurately excluded. - 4G network wireless connection, remote and fast technical support. - Server-level Linux system, computer virus immunity, abnormal power failure without data loss. - Conveyor system adopts belt or chain plate structure, flexible adaptation to the field production line. - Superior to the international radiation safety standards, offering enhanced protection through integrated safety interlocks and monitoring functions.
Categories : Inspection Machine ,
Brand : VIXDETECT
Share
MODEL | VXD-D1825-S |
Sensitivity | SUS ball:0.3mm,SUS Wire :0.2mm*2, Glass/Ceramic Ball:1.0mm |
OS | Linux |
HMI | 17-inch touch screen |
Conveyor Speed | 5~80 m/min |
Product Weight | Max 10kg |
Product Dimension | Max Width 210mm, Max Height 310mm |
Power | AC220V, 50-60Hz |
Environment | Working Temperature 0~45℃, Relative Humidity 30~85% no condensation |
IP Grade | IP66 for Conveyor, IP54 for other parts |
Machine Material | 304 SUS, Mirror/Sandblasted |
